Liquid Scintillant Pump

The pump is separated from the detector eliminating any potential damages caused by leakages. The pump is entirely controlled by the radio detector or the PC software respectively.

The double piston design provides pulsation-free operation and a wide range of the flowrate between 0.001 and 10 mL per minute matches all applications and flow rates of the main HPLC system.

Static Mixer

Two cartridges with 50 and 150 µL volumes are availabel for efficient mixing of eluent and scintillant.

Splitters

To preserve part of the eluate for futher investigations splitters direct only part of it to the scinillant mixer and detector.

Waste Valve

As only part of the eluate is radioactive a waste valve can be applied to divert only the radioactive fraction into a specific container.

RadioStar

Besides controlling the detector the PC software offers sophisticated functions for radiochromatographic data evaluation

• recording of 4 channels: 2 isotopic and 2 non-isotopic signals
• integration of peaks
• half-life correction
• quench correction
• report generation
• export functionality, e.g ANDI format

The software is 21 CFR part 11 compliant.
